25T Mine Diesel Forklift Truck

Model: HNF-250M

Parameters of 25T Mine Diesel Forklift Truck
Configuration Model Unit CPCD250
Vehicle configuration HNF-250M
Performance Rated load kg 25000
Load center mm 1250
Free lift mm 180
Mast tilt angle (front/rear) º 6/12
Overall dimensions Length mm 9115
Width mm 3020
Height mm 3610
Mast lifting height mm 3500
Fork size (L*W*H) mm 2440X280X110
Min. turning radius mm 6500
Max. travel speed (with load) Km/h 28
Lifting speed (with load) mm/s 180
Gradeability (with load) % 20
Weight Kg 32000
Tyre Front 4X14.00-24/28PR
Rear 2X14.00-24/28PR
Wheel tread Front mm 2200
Rear mm 2390
Wheelbase mm 4400
Min. ground clearance mm 230
Engine Model 6CTA8.3-C240
Rated power/rotate speed KW/r.pm 179/2200
Max. torque/rotate speed N.m/r.pm 1029/1500
